Introduction to the XML Parser for C

This section contains the following topics:

See Also:

'Introduction to the XML Parser for Java' for a generic introduction to XML parsing with DOM and SAX. Much of the information in the introduction is language-independent and applies equally to C.

Prerequisites

The Oracle XML parser for C reads an XML document and uses DOM or SAX APIs to provide programmatic access to its content and structure. You can use the parser in validating or nonvalidating mode.

This chapter assumes that you are familiar with the following technologies:

  • Document Object Model (DOM). DOM is an in-memory tree representation of the structure of an XML document.

  • Simple API for XML (SAX). SAX is a standard for event-based XML parsing.

  • Document Type Definition (DTD). An XML DTD defines the legal structure of an XML document.

  • XML Schema. Like a DTD, an XML schema defines the legal structure of an XML document.

  • XML Namespaces. Namespaces are a mechanism for differentiating element and attribute names.

If you require a general introduction to the preceding technologies, consult the XML resources listed in 'Related Documents' of the preface.

Standards and Specifications

XML 1.0 is a W3C Recommendation. The C XDK API provides full support for XML 1.0 (Second Edition). You can find the specification for the Second Edition at the following URL:

The DOM Level 1, Level 2, and Level 3 specifications are W3C Recommendations. The C XDK API provides full suport for DOM Level 1 and 2, but no support for Level 3. You can find links to the specifications for all three levels at the following URL:

SAX is available in version 1.0, which is deprecated, and 2.0. SAX is not a W3C specification. The C XDK API provides full support for both SAX 1.0 and 2.0. You can find the documentation for SAX at the following URL:

XML Namespaces are a W3C Recommendation. You can find the specification at the following URL:

See Also:

XmlChapter 29, 'XDK Standards' for a summary of the standards supported by the XDK

Using the XML Parser for C

Oracle XML parser for C checks if an XML document is well-formed, and optionally validates it against a DTD. Your application can access the parsed data through the DOM or SAX APIs.

This section contains the following topics:

Overview of the Parser API for C

The core of the XML parsing API are the XML, DOM, and SAX APIs. Table 15-1 describes the interfaces for these APIs. Refer to Oracle XML API Reference for the complete API documentation.

Table 15-1 Interfaces for XML, DOM, and SAX APIs

PackageInterfacesFunction Name Convention
XMLThis package implements a single XML interface. The interface defines functions for the following tasks:
  • Creating and destroying contexts. A top-level XML context (xmlctx) shares common information between cooperating XML components.

  • Creating and parsing XML documents and DTDs.

Function names begin with the string Xml. Refer to Oracle Database XML C API Reference for API documentation.
DOMThis package provides programmatic access to parsed XML. The package implements the following interfaces:
  • Attr defines get and set functions for XML attributes.

  • CharacterData defines functions for manipulating character data.

  • Document defines functions for creating XML nodes, obtaining information about an XML document, and setting the DTD for a document.

  • DocumentType defines get functions for DTDs.

  • Element defines get and set functions for XML elements.

  • Entity defines get functions for XML entities.

  • NamedNodeMap defines get functions for named nodes.

  • Node defines get and set functions for XML nodes.

  • NodeList defines functions that free a node list and get a node from a list.

  • Notation defines functions that get the system and public ID from a node.

  • ProcessingInstruction defines get and set functions for processing instructions.

  • Clan macgregor. Text defines a function that splits a text node into two.

Function names begin with the string XmlDom. Refer to Oracle Database XML C API Reference for API documentation.
SAXThis package provides programmatic access to parsed XML. The package implements the SAX interface, which defines functions that receive notifications for SAX events.Function names begin with the string XmlSax. Refer to Oracle Database XML C API Reference for API documentation.

XML Parser for C Datatypes

Refer to Oracle XML API Reference for the complete list of datatypes for the C XDK. Table 15-2 describes the datatypes used in the XML parser for C.

Table 15-2 Datatypes Used in the XML Parser for C

DatatypeDescription

oratext

String pointer

xmlctx

Master XML context

xmlsaxcb

SAX callback structure (SAX only)

ub4

32-bit (or larger) unsigned integer

uword

Native unsigned integer

Convert

XML Parser for C Defaults

Note the following defaults for the XML parser for C:

  • Character set encoding is UTF-8. If all your documents are ASCII, then setting the encoding to US-ASCII increases performance.

  • The parser prints messages to stderr unless an error handler is provided.

  • The parser checks inputs documents for well-formedness but not validity. You can set the property 'validate' to validate the input.

    Note:

    It is recommended that you set the default encoding explicitly if using only single byte character sets (such as US-ASCII or any of the ISO-8859 character sets) for faster performance than is possible with multibyte character sets such as UTF-8.
  • The parser conforms to the XML 1.0 specification when processing whitespace, that is, the parser reports all whitespace to the application but indicates which whitespace can be ignored. However, some applications may prefer to set the property 'discard-whitespace,' which discards all whitespace between an end-element tag and the following start-element tag.

See Also:

  • Oracle Database XML C API Reference for the DOM, SAX, and callback APIs

Using the XML Parser for C: Basic Process

Figure 15-1 illustrates the calling sequence for the XML parser for C.

Figure 15-1 XML Parser for C Calling Sequence


Description of the illustration adxdk096.gif

Perform the following steps in your application:

  1. Initialize the parsing process with the XmlCreate() function. The following sample code fragment is from DOMNamespace.c:

  2. Parse the input item, which can be an XML document or string buffer

    If you are parsing with DOM, call the XmlLoadDom() function. The following sample code fragment is from DOMNamespace.c:

    If you are parsing with SAX, call the XmlLoadSax() function. The following sample code fragment is from SAXNamespace.c:

  3. If you are using the DOM interface, then include the following steps:

    • Use the XmlLoadDom() function to call XmlDomGetDocElem(). This step calls other DOM functions, which are typically node or print functions that output the DOM document, as required. The following sample code fragment is from DOMNamespace.c:

    • Invoke the XmlFreeDocument() function to clean up any data structures created during the parse process. The following sample code fragment is from DOMNamespace.c:

    If you are using the SAX interface, then include the following steps:

    • Process the results of the invocation of XmlLoadSax() with callback functions.

    • Register the callback functions. Note that you can set any of the SAX callback functions to NULL if not needed.

  4. Use XmlFreeDocument() to clean up the memory and structures used during a parse. The program does not free memory allocated for parameters passed to the SAX callbacks or for nodes and data stored with the DOM parse tree until you call XMLFreeDocument() or XMLDestroy(). The following sample code fragment is from DOMNamespace.c:

    Either return to Step 2 or proceed to the next step.

  5. Terminate the parsing process with XmlDestroy(). The following sample code fragment is from DOMNamespace.c:

    If threads fork off somewhere in the sequence of calls between initialization and termination, the application produces unpredictable behavior and results.

You can use the memory callback functions XML_ALLOC_F and XML_FREE_F for your own memory allocation. If you do, then specify both functions.

Convert Xml Free

Running the XML Parser for C Demo Programs

The $ORACLE_HOME/xdk/demo/c/ (UNIX) and %ORACLE_HOME%xdkdemoc (Windows) directories include several XML applications that illustrate how to use the XML parser for C with the DOM and SAX interfaces. Table 15-3 describes the demos.

Table 15-3 C Parser Demos

DirectoryContentsDemos
domThe make utility compiles source files name.c to produce demo program name and output file name.out . The name.std is the expected output.

The following demo programs use the DOM API:

  • The DOMNamespace program uses Namespace extensions to the DOM API. It prints out all elements and attributes of NSExample.xml along with full namespace information.

  • The DOMSample program uses DOM APIs to display an outline of Cleopatra, that is, the XML elements ACT and SCENE. The cleo.xml document contains the XML version of Shakespeare's The Tragedy of Antony and Cleopatra.

  • The FullDom program shows sample usage of the full DOM interface. It exercises all the calls. The program accepts FullDom.xml, which shows the use of entities, as input.

  • The Traverse program illustrates the use of DOM iterators, tree walkers, and ranges. The program accepts the class.xml document, which describes a college Calculus course, as input.

  • The XPointer program illustrates the use of the XML Pointer Language by locating the children of the <pantry> element in pantry.xml.

saxThe make utility compiles source files name.c to produce demo program name and output file name.out . The name.std is the expected output.

The following demo programs use the SAX APIs:

  • The SAXNamespace program uses namespace extensions to the SAX API. It prints out all elements and attributes of NSExample.xml along with full namespace information.

  • The SAXSample program uses SAX APIs to show all lines in the play Cleopatra containing a given word. If you do not specify a word, then it uses the word 'death.' The cleo.xml document contains the XML version of Shakespeare's The Tragedy of Antony and Cleopatra.


You can find documentation that describes how to compile and run the sample programs in the README in the same directory. The basic steps are as follows:

  1. Change into the $ORACLE_HOME/xdk/demo/c directory (UNIX) or %ORACLE_HOME%xdkdemoc directory (Windows).

  2. Make sure that your environment variables are set as described in 'Setting C XDK Environment Variables on UNIX' and 'Setting C XDK Environment Variables on Windows'.

  3. Run make (UNIX) or Make.bat (Windows) at the system prompt. The make utility changes into each demo subdirectory and runs make to do the following:

    1. Compiles the C source files with the cc utility. For example, the Makefile in the $ORACLE_HOME/xdk/demo/c/dom directory includes the following line:

    2. Runs each demo program and redirects the output to a file. For example, the Makefile in the $ORACLE_HOME/xdk/demo/c/dom directory includes the following line:

  4. Compare the *.std files to the *.out files for each program. The *.std file contains the expected output for each program. For example, DOMSample.std contains the expected output from running DOMSample.

Using the C XML Parser Command-Line Utility

The xml utility, which is located in $ORACLE_HOME/bin (UNIX) or %ORACLE_HOME%bin (Windows), is a command-line interface that parses XML documents. It checks for both well-formedness and validity.

C sharp convert xml to string

To use xml ensure that your environment is set up as described in 'Setting C XDK Environment Variables on UNIX' and 'Setting C XDK Environment Variables on Windows'.

Use the following syntax on the command line to invoke xml (the Windows version is xml.exe):

Table 15-4 describes the command-line options.

Table 15-4 C Parser Command-Line Options

OptionDescription
-B BaseURISets the base URI for the XSLT processor. The base URI of http://pqr/xsl.txt resolves pqr.txt to http://pqr/pqr.txt.
-cChecks well-formedness, but performs no validation.
-eencodingSpecifies default input file encoding ('incoding').
-EencodingSpecifies DOM/SAX encoding ('outcoding').
-ffileInterprets the file as filespec, not URI.
-Gxptr_exprsEvaluates XPointer scheme examples given in a file.
-hShows usage help and basic list of command-line options.
-hhShows complete list command-line options.
-inSpecifies the number of times to iterate the XSLT processing.
-llanguageSpecifies the language for error reporting.
-nTraverses the DOM and reports the number of elements, as shown in the following sample output:
-oXSLoutfileSpecifies the output file of the XSLT processor.
-pPrints the document/DTD structures after the parse. For example, the root element <greeting>hello</greeting> is printed as:
-PPrints the document from the root element. For example, the root element <greeting>hello</greeting> is printed as:
-PPPrints from the root node (DOC) and includes the XML declaration.
-PE encodingSpecifies the encoding for -P or -PP output.
-PXIncludes the XML declaration in the output.
-sstylesheetSpecifies the XSLT stylesheet.
-vDisplays the XDK parser version and then exits.
-Vvar valueTests top-level variables in CXSLT.
-wPreserves all whitespace.
-WStops parsing after a warning.
-xExercises the SAX interface and prints the document, as shown in the following sample output:

Using the XML Parser Command-Line Utility: Example

You can test xml on the various XML files located in $ORACLE_HOME/xdk/demo/c. Example 15-1 displays the contents of NSExample.xml.

You can parse this file, count the number of elements, and display the DOM tree as shown in the following example:

The output is shown in the next example.

Example 15-2 xml.out

Using the DOM API for C

This section contains the following topics:

Creating the Top-Level Context

When using the DOM to process XML in a traditional file system or on the Web, you need to perform implementation-specific steps only for startup.

Convert Xml To Word

Your application requires a top-level xmlctx. This context contains encoding information, low-level memory callbacks, error message language, encoding, and so on. In short, this context contains those things that should remain consistent for all XDK components. The basic steps for initialization are as follows:

  1. Allocate an xmlctx with XmlCreate(). For example:

  2. Load documents and generate DOM events. After the application obtains an xmlctx, it can load a serialized XML document with the XmlLoadDom() or XmlLoadSax() functions. Given the Document node, all API DOM functions are available. You can generate DOM as in the following example:

    To generate SAX events, you need a SAX callback structure as shown in the following example:

  3. You can tear down the XML context with the XmlDestroy() function.

Controlling the Data Encoding of XML Documents for the C API

XML data occurs in many encodings. You can control the XML encoding in the following ways:

  • Specify a default encoding to assume for files that are not self-describing

  • Specify the presentation encoding for DOM or SAX

  • Re-encode when a DOM is serialized

Input XML data is always encoded. Some encodings are entirely self-describing, such as UTF-16, which requires a specific BOM before the start of the actual data. The XMLDecl or MIME header of the document can also specify an encoding. If the application cannot determine the specific encoding, then it applies the default input encoding. If you do not provide a default, then the application assumes UTF-8 on ASCII platforms and UTF-E on EBCDIC platforms.

The API makes a provision for cases when the encoding data of the input document is corrupt. For example, suppose an ASCII document with an XMLDecl of encoding=ascii is blindly converted to EBCDIC. The new EBCDIC document contains (in EBCDIC) an XMLDecl that incorrectly claims the document is ASCII. The correct behavior for a program that is re-encoding XML data is to regenerate but not convert the XMLDecl. The XMLDecl is metadata, not data itself. This rule is often ignored, however, which results in corrupt documents. To work around this problem, the API provides an additional flag that enables you to forcibly set the input encoding, thereby overcoming an incorrect XMLDecl.

The precedence rules for determining input encoding are as follows:

  1. Forced encoding as specified by the user

    Caution:

    Forced encoding can result in a fatal error if there is a conflict. For example, the input document is UTF-16 and starts with a UTF-16 BOM, but the user specifies a forced UTF-8 encoding. In this case, the parser will object about the conflict.
  2. Protocol specification (HTTP header, and so on)

  3. XMLDecl specification

  4. User's default input encoding

  5. The default, which is UTF-8 on ASCII platforms or UTF-E on EBCDIC platforms

C# Convert Xml To Csv

After the application has determined the input encoding has been determined, it can parse the document and present the data. You are allowed to choose the presentation encoding; the data will be in that encoding regardless of the original input encoding.

When an application writes back a DOM in serialized form, it can choose at that time to re-encode the presentation data. Thus, the you can place the serialized document in any encoding.

Using NULL-Terminated and Length-Encoded C API Functions

The native string representation in C is NULL-terminated. Thus, the primary DOM interface takes and returns NULL-terminated strings. When stored in table form, however, Oracle XML DB data is not NULL-terminated but length-encoded. Consequently, the XDK provides an additional set of length-encoded APIs for the high-frequency cases to improve performance. In particular, the DOM functions in Table 15-5 have dual APIs.

Table 15-5 NULL-Terminated and Length-Encoded C API Functions

NULL-Terminated APILength-Encoded API
XmlDomGetNodeName()XmlDomGetNodeNameLen()
XmlDomGetNodeLocal()XmlDomGetNodeLocalLen()
XmlDomGetNodeURI()XmlDomGetNodeURILen()
XmlDomGetNodeValue()XmlDomGetNodeValueLen()
XmlDomGetAttrName()XmlDomGetAttrNameLen()
XmlDomGetAttrLocal()XmlDomGetAttrLocalLen()
XmlDomGetAttrURI()XmlDomGetAttrURILen()
XmlDomGetAttrValue()XmlDomGetAttrValueLen()

Handling Errors with the C API

The C API functions typically either return a numeric error code (0 for success, nonzero on failure), or pass back an error code through a variable. In all cases, the API stores error codes. Your application can retrieve the most recent error by calling the XmlDomGetLastError() function.

By default, the API outputs error messages to stderr. However, you can register an error message callback at initialization time. When an error occurs, the application invokes the registered callback and does not print an error.

Xml

Using the SAX API for C

To use SAX, initialize an xmlsaxcb structure with function pointers and pass it to the XmlLoadSax() call. You can also include a pointer to a user-defined context structure, which you pass to each SAX function.

See Also:

Oracle Database XML C API Reference for the SAX callback structure

Using OCI and the XDK C API

This section contains the following topics:

Using XMLType Functions and Descriptions

You can use the C API for XML for XMLType columns in the database. An Oracle Call Interface (OCI) program can access XML data stored in a table by initializing the values of OCI handles such as the following:

The program can pass these input values to the function OCIXmlDbInitXmlCtx(), which returns an XML context. After the program makes calls to the C API, the function OCIXmlDbFreeXmlCtx() frees the context.

Table 15-6 describes a few of the functions for XML operations.

Table 15-6 XMLType Functions

Function NameDescription
XmlCreateDocument()Create empty XMLType instance
XmlLoadDom() and so onCreate from a source buffer
XmlXPathEvalexpr() and familyExtract an XPath expression
XmlXslProcess() and familyTransform using an XSLT stylesheet
XmlXPathEvalexpr() and familyCheck if an XPath exists
XmlDomIsSchemaBased()Is document schema-based?
XmlDomGetSchema()Get schema information
XmlDomGetNodeURI()Get document namespace
XmlSchemaValidate()Validate using schema
Cast (void *) to (xmldocnode *)Obtain DOM from XMLType
Cast (xmldocnode *) to (void *)Obtain XMLType from DOM

Initializing an XML Context

An XML context is a required parameter in all the C DOM API functions. This opaque context encapsulates information pertaining to data encoding, error message language, and so on. The contents of this XML context are different for XDK applications and for Oracle XML DB applications.

Convert

Caution:

Convert C To Xml

Do not use an XML context for XDK in an XML DB application, or an XML context for XML DB in an XDK application.

For Oracle XML DB, the two OCI functions that initialize and free an XML context have the following prototypes:

See Also:

  • Oracle Call Interface Programmer's Guide for reference material on the functions.

  • Oracle Call Interface Programmer's Guide for a discussion about OCI support for XML.

  • Oracle Database XML C API Reference for reference information on the DOM APIs

Creating XMLType Instances on the Client

You can construct new XMLType instances on the client by using the XmlLoadDom() calls. Follow these basic steps:

  1. You first have to initialize the xmlctx, as illustrated in the example in 'Using the DOM API for C'.

  2. You can construct the XML data itself from the following sources:

    • User buffer

    • Local file

    • URI

    The return value from these is an (xmldocnode *), which you can use in the rest of the common C API.

  3. Finally, you can cast the (xmldocnode *) to a (void *) and directly provide it as the bind value if required.

You can construct empty XMLType instances by using the XmlCreateDocument() call. This function would be equivalent to an OCIObjectNew() for other types. You can operate on the (xmldocnode *) returned by the preceding call and finally cast it to a (void *) if it needs to be provided as a bind value.

Operating on XML Data in the Database Server

C# Convert Xml To Class Online

You can operate on XML data in Oracle Database by means of OCI statement calls. You can bind and define XMLType values using xmldocnode and use OCI statements to select XML data from the database. You can use this data directly in the C DOM functions. Similarly, you can bind the values directly to SQL statements.

Using OCI and the XDK C API: Examples

Example 15-3 illustrates how to construct a schema-based document with the DOM API and save it to the database. Note that you must include the header files xml.h and ocixmldb.h.

Example 15-3 Constructing a Schema-Based Document with the DOM API

Example 15-4 illustrates how to get a document from the database and modify it with the DOM API.

Example 15-4 Modifying a Database Document with the DOM API
